8-layer BMS protection for safe operation
Extended capacity for longer
backup duration
backup duration
| Cell Chemistry | LFP |
|---|---|
| Rated Capacity | 2009.6 Wh |
| Rated Voltage / Capacity | 6.4V, 314Ah |
| Cycle Life | ≥3000 cycles @ 80% DOD |
| BMS Protection | 8-layer protection: Over-current / Short-circuit / Over-temp / Under-voltage / Over-voltage / Reverse current / Cell balancing / Lightning protection |
| Max AC Output Power | 1000W |
| AC Output Ports | 220V × 2 |
| USB-C Ports | 2 × (12V/1.9A ) |
| USB-A Ports (Qty & Max Power) | 2 × (5V/2A) |
| DC port | DC5521, 12V / 2A |
| AC Input | 185–230V / 50–60Hz |
| DC / Solar Input | MPPT, 500W, 10–55V |
| Net Weight (Approx.) | 28 kg |
| Dimensions | 350 × 250 × 324 mm |
| IP Rating | IP22 |
| Operating Temp (Charge / Discharge) | −20°C to 45°C |
| Operating Humidity | 5–98% (Non-condensing) |
| UPS Function | ≤20ms |
| Display | Indicator LEDs |
